PET Braided Self Closing Cable Wrap
SB-SC-B
Model Number: SB-SC-B
Working temperature: -50ºC ~ +150ºC
Material:PET+PPS
Melting point: 240ºC±10
Flame resistant grade: UL1441 VW-1
Structure
PET braided Self-closing cable wrap offers innovative solutions to the protection of breakout areas and also provides ease of removal when inspection or maintenance of cables is required. The special open structure allows it can be installed after necessary components, for examples copper terminals and connectors. Strong resilience force keeps the wire or the cables not exposed, meanwhile provides excellent abrasion resistance and flame-resistance.
Usage
It is widely used in the protection of various lines such as electronic appliances, high-speed rail industry, automobile industry, communication industry, automation equipment, etc., especially suitable for those that need protection and heat dissipation.
Specification
Dimension
Model Number | Inner diameter(mm) | Max application diameter | Packing(meters/Roll) |
SB-SC-B-005 | 5 | 6 | 100 |
SB-SC-B-008 | 8 | 9 | 100 |
SB-SC-B-010 | 10 | 11 | 100 |
SB-SC-B-013 | 13 | 14 | 100 |
SB-SC-B-016 | 16 | 17 | 50 |
SB-SC-B-019 | 19 | 20 | 50 |
SB-SC-B-025 | 25 | 27 | 25 |
SB-SC-B-030 | 30 | 32 | 25 |
SB-SC-B-038 | 38 | 40 | 25 |
SB-SC-B-050 | 50 | 52 | 25 |
Color: The standard color is black, other colors upon customer’s requirement.
